二进制安装k8s
1.安装环境
1.1实验环境准备
1.1.1主机分配
1.1.2实验环境准备
更改主机名，方便区分角色
时间同步安装ntp服务，计划更新
master节点ssh免密登录全节点
主机系统级优化
1.1.3.高可用集群搭建
安装docker或container版本支持k8s二进制版本
安装HAproxy+keepalive配置vip保证高可用
2.安装准备
2.1下载k8s二进制包
2.1.1 二进制k8s下载地址
https://github.com/kubernetes/kubernetes
https://github.com/kubernetes/kubernetes/blob/master/CHANGELOG/CHANGELOG-1.21.md#server-binaries
2.1.2 使用我们上传的软件包
[root@master1 ~]# lsanaconda-ks.cfg original-ks.cfgkubernetes-server-linux-amd64.tar.gz start_up.sh
[root@master1 ~]# tar -zxvf kubernetes-server-linux-amd64.tar.gz
[root@master1 ~]# cd kubernetes/server/bin/
#将kube-apiserver kube-aggregator kube-controller-manager kubectl kubelet kube-proxy kube-scheduler命令传递到管理节点
[root@master1 bin]# for i in master1 master2 master3;do scp kube-apiserver kube-aggregator kube-controller-manager kubectl kubelet kube-proxy kube-scheduler $i:/usr/local/bin;done
#将kubelet kube-proxy命令传递到普通节点
[root@master1 bin]# for i in node1 node2;do scp kubelet kube-proxy $i:/usr/local/bin;done
[root@master1 bin]# cd2.2CA证书创建和分发
从k8s的1.8版本开始，K8S系统各组件需要使用TLS证书对通信进行加密。每一个K8S集群都需要独立的CA证书体系。CA证书有以下三种：easyrsa、openssl、cfssl。这里使用cfssl证书，也是目前使用最多的，相对来说配置简单一些，通过json的格式，把证书相关的东西配置进去即可。这里使用cfssl的版本为1.6版本。
2.1.1所有master节点生成证书目录
#所有master节点生成证书目录
[root@master1 ~]# mkdir -p /etc/etcd/ssl
[root@master2 ~]# mkdir -p /etc/etcd/ssl/
[root@master3 ~]# mkdir -p /etc/etcd/ssl/
#所有master节点生成k8s证书目录
[root@master1 ~]# mkdir -p /etc/kubernetes/pki
[root@master2 ~]# mkdir -p /etc/kubernetes/pki
[root@master3 ~]# mkdir -p /etc/kubernetes/pki2.1.2 安装CFSSL
2.1.2.1、 网络下载地址：（下载很慢，使用我们上传的文件）
wget https://github.com/cloudflare/cfssl/releases/download/v1.6.1/cfssl_1.6.1_linux_amd64
wget https://github.com/cloudflare/cfssl/releases/download/v1.6.1/cfssl-certinfo_1.6.1_linux_amd64
wget https://github.com/cloudflare/cfssl/releases/download/v1.6.1/cfssljson_1.6.1_linux_amd64
#把3个文件放到/usr/local/bin目录下，或者做软连接也可以
[root@master1 ~]# ls
anaconda-ks.cfg kubernetes
cfssl_1.6.1_linux_amd64 kubernetes-server-linux-amd64.tar.gz
cfssl-certinfo_1.6.1_linux_amd64
cfssljson_1.6.1_linux_amd64
#把3个文件放到/usr/local/bin目录下，或者做软连接也可以
#改个名-可以不改
[root@master1 ~]# mv cfssl_1.6.1_linux_amd64 cfssl
[root@master1 ~]# mv cfssljson_1.6.1_linux_amd64 cfssljson
[root@master1 ~]# mv cfssl-certinfo_1.6.1_linux_amd64 cfssl-certinfo
[root@master1 ~]# ls
anaconda-ks.cfg cfssljson original-ks.cfg
cfssl kubernetes start_up.sh
cfssl-certinfo kubernetes-server-linux-amd64.tar.gz
[root@master1 ~]# ln cfssl* /usr/local/bin/
[root@master1 ~]# chmod +x /usr/local/bin/cfssl*
[root@master1 ~]# ls /usr/local/bin/
2.1.3 创建用来生成CA证书的json配置文件
[root@master1 ~]# mkdir ssl[root@master1 ~]# cd ssl
[root@master1 ssl]# vim ca-config.json
{
"signing": {
"default": {
"expiry": "876000h"
},
"profiles": {
"kubernetes": {
"usages": [
"signing",
"key encipherment",
"server auth",
"client auth"
],
"expiry": "876000h"
}
}
}
}signing: 表示该证书可用于签名其它证书；生成的 ca.pem 证书中 CA=TRUE; server auth: 表示 client 可以用该 CA 对 server 提供的证书进行验证; client auth: 表示 server 可以用该 CA 对 client 提供的证书进行验证;
2.1.4 创建etcd证书
2.1.4.1 生成etcd根证书请求文件
[root@master1 ssl]# vim etcd-ca-csr.json
{
"CN": "etcd",
"key": {
"algo": "rsa",
"size": 2048
},
"names": [
{
"C": "CN",
"ST": "Beijing",
"L": "Beijing",
"O": "etcd",
"OU": "Etcd Security"
}
],
"ca": {
"expiry": "876000h"
}
}[root@master1 ssl]# cfssl gencert -initca etcd-ca-csr.json | cfssljson -bare /etc/etcd/ssl/etcd-ca
[root@master1 ssl]# ls /etc/etcd/ssl/etcd-ca.csr etcd-ca-key.pem etcd-ca.pem
2.1.4.2 生成etcd客户端证书
[root@master1 ssl]# vim etcd-csr.json
{
"CN": "etcd",
"key": {
"algo": "rsa",
"size": 2048
},
"names": [
{
"C": "CN",
"ST": "Beijing",
"L": "Beijing",
"O": "etcd",
"OU": "Etcd Security"
}
]
} cfssl gencert \
-ca=/etc/etcd/ssl/etcd-ca.pem \
-ca-key=/etc/etcd/ssl/etcd-ca-key.pem \
-config=ca-config.json \
-hostname=127.0.0.1,20.20.20.56,20.20.20.57,20.20.20.13 \
-profile=kubernetes \
etcd-csr.json | cfssljson -bare /etc/etcd/ssl/etcd
2.1.4.3、 拷贝证书到其他节点
定义etcd节点 奇数节点
[root@master1 ssl]# masternode="master1 master2 master3"[root@master1 ssl]# for i in i:/etc/etcd/ssl/;done
for i in $masternode;do scp -r /etc/etcd/ssl/*.pem $i:/etc/etcd/ssl/;done[root@master1 ssl]# ln -s /etc/etcd/ssl /etc/kubernetes/pki/etcd
[root@master2 ~]# ln -s /etc/etcd/ssl /etc/kubernetes/pki/etcd
[root@master3 ~]# ln -s /etc/etcd/ssl /etc/kubernetes/pki/etcd
2.1.5 创建k8s集群证书
2.1.5.1 生成k8s集群CA证书的csr文件
[root@master1 ssl]# vim ca-csr.json
{
"CN": "kubernetes",
"key": {
"algo": "rsa",
"size": 2048
},
"names": [
{
"C": "CN",
"ST": "Beijing",
"L": "Beijing",
"O": "Kubernetes",
"OU": "Kubernetes-manual"
}
],
"ca": {
"expiry": "876000h"
}
}2.1.5.2、 生成k8s CA证书
[root@master1 ssl]# cfssl gencert -initca ca-csr.json | cfssljson -bare /etc/kubernetes/pki/ca
2.1.6 创建apiserver客户端证书
2.1.6.1 创建apiserver csr文件
[root@master1 ssl]# vim apiserver-csr.json
{
"CN": "kube-apiserver",
"key": {
"algo": "rsa",
"size": 2048
},
"names": [
{
"C": "CN",
"ST": "Beijing",
"L": "Beijing",
"O": "Kubernetes",
"OU": "Kubernetes-manual"
}
]
}“CN”：Common Name，kube-apiserver 从证书中提取该字段作为请求的用户名 (User Name)；浏览器使用该字段验证网站是否合法； “O”：Organization，kube-apiserver 从证书中提取该字段作为请求用户所属的组 (Group)；
2.1.6.2、 创建apiserver客户端证书
[root@master1 ssl]# cfssl gencert -ca=/etc/kubernetes/pki/ca.pem -ca-key=/etc/kubernetes/pki/ca-key.pem -config=ca-config.json -hostname=127.0.0.1,20.20.20.88,172.17.0.1,kubernetes,kubernetes.default,kubernetes.default.svc,kubernetes.default.svc.cluster,kubernetes.default.svc.cluster.local,20.20.20.56,20.20.20.57,20.20.20.13 -profile=kubernetes apiserver-csr.json | cfssljson -bare /etc/kubernetes/pki/apiserver
cfssl gencert -ca=/etc/kubernetes/pki/ca.pem -ca-key=/etc/kubernetes/pki/ca-key.pem -config=ca-config.json -hostname=127.0.0.1,20.20.20.88,172.17.0.1,kubernetes,kubernetes.default,kubernetes.default.svc,kubernetes.default.svc.cluster,kubernetes.default.svc.cluster.local,20.20.20.56,20.20.20.57,20.20.20.13 -profile=kubernetes apiserver-csr.json | cfssljson -bare /etc/kubernetes/pki/apiserver
2.1.7 创建front-proxy-ca证书
2.1.7.1 创建front-proxy-ca证书
API聚合证书，主要做流量过滤
[root@master1 ssl]# vim front-proxy-ca-csr.json
{
"CN": "kubernetes",
"key": {
"algo": "rsa",
"size": 2048
}
}[root@master1 ssl]# cfssl gencert -initca front-proxy-ca-csr.json | cfssljson -bare /etc/kubernetes/pki/front-proxy-ca
2.1.7.2 创建front-proxy-client证书
[root@master1 ssl]# vim front-proxy-client-csr.json
{
"CN": "front-proxy-client",
"key": {
"algo": "rsa",
"size": 2048
}
}[root@master1 ssl]# cfssl gencert -ca=/etc/kubernetes/pki/front-proxy-ca.pem -ca-key=/etc/kubernetes/pki/front-proxy-ca-key.pem -config=ca-config.json -profile=kubernetes front-proxy-client-csr.json | cfssljson -bare /etc/kubernetes/pki/front-proxy-client
2.1.8 创建Controller Manager证书
2.1.8.1 创建csr文件
[root@master1 ssl]# vim manager-csr.json
{
"CN": "system:kube-controller-manager",
"key": {
"algo": "rsa",
"size": 2048
},
"names": [
{
"C": "CN",
"ST": "Beijing",
"L": "Beijing",
"O": "system:kube-controller-manager",
"OU": "Kubernetes-manual"
}
]
}2.1.8.2、 生成Controller Manager证书
[root@master1 ssl]# cfssl gencert \
-ca=/etc/kubernetes/pki/ca.pem \-ca-key=/etc/kubernetes/pki/ca-key.pem \-config=ca-config.json \-profile=kubernetes \manager-csr.json | cfssljson -bare /etc/kubernetes/pki/controller-manager
cfssl gencert \
-ca=/etc/kubernetes/pki/ca.pem \
-ca-key=/etc/kubernetes/pki/ca-key.pem \
-config=ca-config.json \
-profile=kubernetes \
manager-csr.json | cfssljson -bare /etc/kubernetes/pki/controller-manager
2.1.8.3、 设置集群参数
[root@master1 ssl]# kubectl config set-cluster kubernetes \
--certificate-authority=/etc/kubernetes/pki/ca.pem \--embed-certs=true \--server=https://20.20.20.88:16443 \--kubeconfig=/etc/kubernetes/controller-manager.kubeconfigCluster "kubernetes" set.
kubectl config set-cluster kubernetes \
--certificate-authority=/etc/kubernetes/pki/ca.pem \
--embed-certs=true \
--server=https://20.20.20.88:16443 \
--kubeconfig=/etc/kubernetes/controller-manager.kubeconfig2.1.8.4、 设置一个用户
kubectl config set-credentials system:kube-controller-manager \
--client-certificate=/etc/kubernetes/pki/controller-manager.pem \
--client-key=/etc/kubernetes/pki/controller-manager-key.pem \
--embed-certs=true \
--kubeconfig=/etc/kubernetes/controller-manager.kubeconfig2.1.8.5、 设置上下文参数
kubectl config set-context system:kube-controller-manager@kubernetes \
--cluster=kubernetes \
--user=system:kube-controller-manager \
--kubeconfig=/etc/kubernetes/controller-manager.kubeconfig2.1.8.6、 设置默认上下文环境
kubectl config use-context system:kube-controller-manager@kubernetes \
--kubeconfig=/etc/kubernetes/controller-manager.kubeconfig2.1.9 创建scheduller证书
[root@master1 ssl]# vim scheduler-csr.json
{
"CN": "system:kube-scheduler",
"key": {
"algo": "rsa",
"size": 2048
},
"names": [
{
"C": "CN",
"ST": "Beijing",
"L": "Beijing",
"O": "system:kube-scheduler",
"OU": "Kubernetes-manual"
}
]
}[root@master1 ssl]# cfssl gencert -ca=/etc/kubernetes/pki/ca.pem -ca-key=/etc/kubernetes/pki/ca-key.pem -config=ca-config.json -profile=kubernetes scheduler-csr.json | cfssljson -bare /etc/kubernetes/pki/scheduler
2.1.9.1、 设置集群参数
kubectl config set-cluster kubernetes \
--certificate-authority=/etc/kubernetes/pki/ca.pem \
--embed-certs=true \
--server=https://20.20.20.88:16443 \
--kubeconfig=/etc/kubernetes/scheduler.kubeconfig2.1.9.1、 设置一个用户
kubectl config set-credentials system:kube-scheduler \
--client-certificate=/etc/kubernetes/pki/scheduler.pem \
--client-key=/etc/kubernetes/pki/scheduler-key.pem \
--embed-certs=true \
--kubeconfig=/etc/kubernetes/scheduler.kubeconfig2.1.9.1、 设置上下文参数
kubectl config set-context system:kube-scheduler@kubernetes \
--cluster=kubernetes \
--user=system:kube-scheduler \
--kubeconfig=/etc/kubernetes/scheduler.kubeconfig2.1.9.1、 设置默认上下文环境
kubectl config use-context system:kube-scheduler@kubernetes \
--kubeconfig=/etc/kubernetes/scheduler.kubeconfig
2.1.10 创建admin证书
[root@master1 ssl]# vim admin-csr.json
{
"CN": "admin",
"key": {
"algo": "rsa",
"size": 2048
},
"names": [
{
"C": "CN",
"ST": "Beijing",
"L": "Beijing",
"O": "system:masters",
"OU": "Kubernetes-manual"
}
]
}[root@master1 ssl]# cfssl gencert -ca=/etc/kubernetes/pki/ca.pem -ca-key=/etc/kubernetes/pki/ca-key.pem -config=ca-config.json -profile=kubernetes admin-csr.json | cfssljson -bare /etc/kubernetes/pki/admin
2.1.10.1 设置集群参数
kubectl config set-cluster kubernetes \
--certificate-authority=/etc/kubernetes/pki/ca.pem \
--embed-certs=true \
--server=https://20.20.20.88:16443 \
--kubeconfig=/etc/kubernetes/admin.kubeconfig2.1.10.2设置一个用户
kubectl config set-credentials kubernetes-admin \
--client-certificate=/etc/kubernetes/pki/admin.pem \
--embed-certs=true \
--client-key=/etc/kubernetes/pki/admin-key.pem \
--kubeconfig=/etc/kubernetes/admin.kubeconfig2.1.11.3 设置上下文参数
kubectl config set-context kubernetes-admin@kubernetes \
--cluster=kubernetes \
--user=kubernetes-admin \
--kubeconfig=/etc/kubernetes/admin.kubeconfig2.1.12.4 设置默认环境
kubectl config use-context kubernetes-admin@kubernetes \
--kubeconfig=/etc/kubernetes/admin.kubeconfig
2.1.11 生成service-account的key
[root@master1 ssl]# openssl genrsa -out /etc/kubernetes/pki/sa.key 2048
[root@master1 ssl]# openssl rsa -in /etc/kubernetes/pki/sa.key -pubout -out /etc/kubernetes/pki/sa.pub
2.1.12 拷贝证书到其他master节点
[root@master1 ssl]# for i in master2 master3;do scp -r /etc/kubernetes/* $i:/etc/kubernetes/;done
2.3 ETCD集群部署
所有持久化的状态信息以K/V的形式存储在ETCD中。类似zookeeper，提供分布式协调服务。之所以说kubenetes各个组件是无状态的，就是因为其中把数据都存放在ETCD中。由于ETCD支持集群，这里在三台主机上都部署上ETCD。
2.3.1、 准备ETCD二进制文件
二进制包下载地址：
wget https://storage.googleapis.com/etcd/v3.4.13/etcd-v3.4.13-linux-amd64.tar.gz[root@master1 ssl]# cd[root@master1 ~]# tar -zxvf etcd-v3.4.13-linux-amd64.tar.gz
2.3.2、 拷贝二进制文件到指定目录
[root@master1 etcd-v3.4.13-linux-amd64]# for i in master1 master2 master3;do scp etcd etcdctl $i:/usr/local/bin/;done
2.3.3、 设置etcd配置文件
[root@master1 etcd-v3.4.13-linux-amd64]# vim /etc/etcd/etcd.config.yml
name: 'master1'
data-dir: /var/lib/etcd
wal-dir: /var/lib/etcd/wal
snapshot-count: 5000
heartbeat-interval: 100
election-timeout: 1000
quota-backend-bytes: 0
listen-peer-urls: 'https://20.20.20.56:2380'
listen-client-urls: 'https://20.20.20.56:2379,http://127.0.0.1:2379'
max-snapshots: 3
max-wals: 5
cors:
initial-advertise-peer-urls: 'https://20.20.20.56:2380'
advertise-client-urls: 'https://20.20.20.56:2379'
discovery:
discovery-fallback: 'proxy'
discovery-proxy:
discovery-srv:
initial-cluster: 'master1=https://20.20.20.56:2380,master2=https://20.20.20.57:2380,master3=https://20.20.20.13:2380'
initial-cluster-token: 'etcd-k8s-cluster'
initial-cluster-state: 'new'
strict-reconfig-check: false
enable-v2: true
enable-pprof: true
proxy: 'off'
proxy-failure-wait: 5000
proxy-refresh-interval: 30000
proxy-dial-timeout: 1000
proxy-write-timeout: 5000
proxy-read-timeout: 0
client-transport-security:
cert-file: '/etc/kubernetes/pki/etcd/etcd.pem'
key-file: '/etc/kubernetes/pki/etcd/etcd-key.pem'
client-cert-auth: true
trusted-ca-file: '/etc/kubernetes/pki/etcd/etcd-ca.pem'
auto-tls: true
peer-transport-security:
cert-file: '/etc/kubernetes/pki/etcd/etcd.pem'
key-file: '/etc/kubernetes/pki/etcd/etcd-key.pem'
peer-client-cert-auth: true
trusted-ca-file: '/etc/kubernetes/pki/etcd/etcd-ca.pem'
auto-tls: true
debug: false
log-package-levels:
log-outputs: [default]
force-new-cluster: false2.3.4、 etcd 3.4注意事项：
ETCD3.4版本ETCDCTL_API=3 etcdctl 和 etcd --enable-v2=false 成为了默认配置，如要使用v2版本，执行etcdctl时候需要设置ETCDCTL_API环境变量，例如：ETCDCTL_API=2 etcdctl
flannel操作etcd使用的是v2的API，而kubernetes操作etcd使用的v3的API
注意：flannel操作etcd使用的是v2的API，而kubernetes操作etcd使用的v3的API，为了兼容flannel，将默认开启v2版本
2.3.5、 创建etcd系统服务
[root@master1 ~]# vim /usr/lib/systemd/system/etcd.service
[Unit]
Description=Etcd Service
Documentation=https://coreos.com/etcd/docs/latest/
After=network.target
[Service]
Type=notify
ExecStart=/usr/local/bin/etcd --config-file=/etc/etcd/etcd.config.yml
Restart=on-failure
RestartSec=10
LimitNOFILE=65536
[Install]
WantedBy=multi-user.target
Alias=etcd3.service2.3.6 配置文件和服务文件拷贝到其他两个节点
[root@master1 ~]# for i in master2 master3;do scp /etc/etcd/etcd.config.yml i:/usr/lib/systemd/system/;done
for i in master2 master3;do scp /etc/etcd/etcd.config.yml $i:/etc/etcd;scp /usr/lib/systemd/system/etcd.service $i:/usr/lib/systemd/system/;done[root@master2 ~]# vim /etc/etcd/etcd.config.yml 修改ip主机名
name: 'master2' #修改这里
data-dir: /var/lib/etcd
wal-dir: /var/lib/etcd/wal
snapshot-count: 5000
heartbeat-interval: 100
election-timeout: 1000
quota-backend-bytes: 0
listen-peer-urls: 'https://20.20.20.57:2380' #修改这里
listen-client-urls: 'https://20.20.20.57:2379,http://127.0.0.1:2379' #修改这里
max-snapshots: 3
max-wals: 5
cors:
initial-advertise-peer-urls: 'https://20.20.20.57:2380' #修改这里
advertise-client-urls: 'https://20.20.20.57:2379' #修改这里
discovery:
discovery-fallback: 'proxy'
discovery-proxy:
discovery-srv:
initial-cluster: 'master1=https://20.20.20.56:2380,master2=https://20.20.20.57:2380,master3=https://20.20.20.13:2380'[root@master3 ~]# vim /etc/etcd/etcd.config.yml
name: 'master3'
data-dir: /var/lib/etcd
wal-dir: /var/lib/etcd/wal
snapshot-count: 5000
heartbeat-interval: 100
election-timeout: 1000
quota-backend-bytes: 0
listen-peer-urls: 'https://20.20.20.13:2380'
listen-client-urls: 'https://20.20.20.13:2379,http://127.0.0.1:2379'
max-snapshots: 3
max-wals: 5
cors:
initial-advertise-peer-urls: 'https://20.20.20.13:2380'
advertise-client-urls: 'https://20.20.20.13:2379'
discovery:
discovery-fallback: 'proxy'
discovery-proxy:
discovery-srv:
initial-cluster: 'master1=https://20.20.20.56:2380,master2=https://20.20.20.57:2380,master3=https://20.20.20.13:2380'2.3.7、 启动ETCD服务所master节点
[root@master1 ~]# systemctl daemon-reload[root@master1 ~]# systemctl start etcd[root@master1 ~]# systemctl enable etcd[root@master1 ~]# systemctl status etcd
2.3.8、 集群验证
etcdctl --endpoints=https://20.20.20.56:2379,https://20.20.20.57:2379,https://20.20.20.13:2379 \
--cacert=/etc/etcd/ssl/etcd-ca.pem \
--cert=/etc/etcd/ssl/etcd.pem \
--key=/etc/etcd/ssl/etcd-key.pem endpoint status --write-out=table
注意：调整master1为leader
etcdctl --endpoints=https://20.20.20.56:2379,https://20.20.20.57:2379,https://20.20.20.13:2379 \
--cacert=/etc/etcd/ssl/etcd-ca.pem \
--cert=/etc/etcd/ssl/etcd.pem \
--key=/etc/etcd/ssl/etcd-key.pem endpoint health etcdctl --endpoints=https://20.20.20.56:2379,https://20.20.20.57:2379,https://20.20.20.13:2379 \
--cacert=/etc/etcd/ssl/etcd-ca.pem \
--cert=/etc/etcd/ssl/etcd.pem \
--key=/etc/etcd/ssl/etcd-key.pem member list
2.4 Master节点部署
2.4.1、 部署apiserver
2.4.1.1 创建kube-apiserver系统服务
[root@master1 ~]# vim /usr/lib/systemd/system/kube-apiserver.service
[Unit]
Description=Kubernetes API Server
Documentation=https://github.com/kubernetes/kubernetes
After=network.target
[Service]
ExecStart=/usr/local/bin/kube-apiserver \
--v=2 \
--logtostderr=true \
--allow-privileged=true \
--bind-address=0.0.0.0 \
--secure-port=6443 \
--insecure-port=0 \
--advertise-address=20.20.20.56 \
--service-cluster-ip-range=10.96.0.0/16 \
--service-node-port-range=30000-32767 \
--etcd-servers=https://20.20.20.56:2379,https://20.20.20.57:2379,https://20.20.20.13:2379 \
--etcd-cafile=/etc/etcd/ssl/etcd-ca.pem \
--etcd-certfile=/etc/etcd/ssl/etcd.pem \
--etcd-keyfile=/etc/etcd/ssl/etcd-key.pem \
--client-ca-file=/etc/kubernetes/pki/ca.pem \
--tls-cert-file=/etc/kubernetes/pki/apiserver.pem \
--tls-private-key-file=/etc/kubernetes/pki/apiserver-key.pem \
--kubelet-client-certificate=/etc/kubernetes/pki/apiserver.pem \
--kubelet-client-key=/etc/kubernetes/pki/apiserver-key.pem \
--service-account-key-file=/etc/kubernetes/pki/sa.pub \
--service-account-signing-key-file=/etc/kubernetes/pki/sa.key \
--service-account-issuer=https://kubernetes.default.svc.cluster.local \
--kubelet-preferred-address-types=InternalIP,ExternalIP,Hostname \
--enable-admission-plugins=NamespaceLifecycle,LimitRanger,ServiceAccount,DefaultStorageClass,DefaultTolerationSeconds,NodeRestriction,ResourceQuota \
--authorization-mode=Node,RBAC \
--enable-bootstrap-token-auth=true \
--requestheader-client-ca-file=/etc/kubernetes/pki/front-proxy-ca.pem \
--proxy-client-cert-file=/etc/kubernetes/pki/front-proxy-client.pem \
--proxy-client-key-file=/etc/kubernetes/pki/front-proxy-client-key.pem \
--requestheader-allowed-names=aggregator \
--requestheader-group-headers=X-Remote-Group \
--requestheader-extra-headers-prefix=X-Remote-Extra- \
--requestheader-username-headers=X-Remote-User
# --token-auth-file=/etc/kubernetes/token.csv
Restart=on-failure
RestartSec=10s
LimitNOFILE=65535
[Install]
WantedBy=multi-user.target2.4.1.2、 拷贝文件到master2，master3
[root@master1 ~]# for i in master2 master3;do scp /usr/lib/systemd/system/kube-apiserver.service $i:/usr/lib/systemd/system/; done
[root@master2 ~]# vim /usr/lib/systemd/system/kube-apiserver.service
--advertise-address=20.20.20.57 \
[root@master2 ~]# vim /usr/lib/systemd/system/kube-apiserver.service
[root@master3 ~]# vim /usr/lib/systemd/system/kube-apiserver.service
--advertise-address=20.20.20.13 \
2.4.1.3、 启动apiserver
[root@master1 ~]# systemctl daemon-reload[root@master1 ~]# systemctl enable --now kube-apiserver[root@master1 ~]# systemctl status kube-apiserver
2.3.1.4、 通过url访问api接口
curl --cacert /etc/kubernetes/pki/ca.pem --cert /etc/kubernetes/pki/admin.pem --key /etc/kubernetes/pki/admin-key.pem https://20.20.20.56:6443/
curl --cacert /etc/kubernetes/pki/ca.pem --cert /etc/kubernetes/pki/admin.pem --key /etc/kubernetes/pki/admin-key.pem https://20.20.20.57:6443/
curl --cacert /etc/kubernetes/pki/ca.pem --cert /etc/kubernetes/pki/admin.pem --key /etc/kubernetes/pki/admin-key.pem https://20.20.20.13:6443/
curl --cacert /etc/kubernetes/pki/ca.pem --cert /etc/kubernetes/pki/admin.pem --key /etc/kubernetes/pki/admin-key.pem https://20.20.20.88:6443/2.3.5、 部署Controller Manager
2.3.5.1、 创建服务文件
[root@master1 ~]# vim /usr/lib/systemd/system/kube-controller-manager.service
[Unit]
Description=Kubernetes Controller Manager
Documentation=https://github.com/kubernetes/kubernetes
After=network.target
[Service]
ExecStart=/usr/local/bin/kube-controller-manager \
--v=2 \
--logtostderr=true \
--bind-address=127.0.0.1 \
--root-ca-file=/etc/kubernetes/pki/ca.pem \
--cluster-signing-cert-file=/etc/kubernetes/pki/ca.pem \
--cluster-signing-key-file=/etc/kubernetes/pki/ca-key.pem \
--service-account-private-key-file=/etc/kubernetes/pki/sa.key \
--kubeconfig=/etc/kubernetes/controller-manager.kubeconfig \
--leader-elect=true \
--use-service-account-credentials=true \
--node-monitor-grace-period=40s \
--node-monitor-period=5s \
--pod-eviction-timeout=2m0s \
--controllers=*,bootstrapsigner,tokencleaner \
--allocate-node-cidrs=true \
--cluster-cidr=172.168.0.0/16 \
--requestheader-client-ca-file=/etc/kubernetes/pki/front-proxy-ca.pem \
--node-cidr-mask-size=24
Restart=always
RestartSec=10s
[Install]
WantedBy=multi-user.target2.3.5.2、 拷贝文件到其他master节点
[root@master1 ~]# for i in master2 master3;do scp /usr/lib/systemd/system/kube-controller-manager.service $i:/usr/lib/systemd/system/;done
2.3.5.3、 启动服务
[root@master1 ~]# systemctl daemon-reload[root@master1 ~]# systemctl enable --now kube-controller-manager[root@master1 ~]# systemctl status kube-controller-manager
2.3.6、 部署scheduller
2.3.6.1、 创建服务文件
[root@master1 ~]# vim /usr/lib/systemd/system/kube-scheduler.service
[Unit]
Description=Kubernetes Scheduler
Documentation=https://github.com/kubernetes/kubernetes
After=network.target
[Service]
ExecStart=/usr/local/bin/kube-scheduler \
--v=2 \
--logtostderr=true \
--address=127.0.0.1 \
--leader-elect=true \
--kubeconfig=/etc/kubernetes/scheduler.kubeconfig
Restart=always
RestartSec=10s
[Install]
WantedBy=multi-user.target2.3.6.1、 传递到其他master节点
[root@master1 ~]# for i in master2 master3;do scp /usr/lib/systemd/system/kube-scheduler.service $i:/usr/lib/systemd/system/;done
2.3.6.2服务启动
[root@master1 ~]# systemctl daemon-reload[root@master1 ~]# systemctl enable --now kube-scheduler[root@master1 ~]# systemctl status kube-scheduler
2.3.7、 创建**bootstrap**
在安装 Kubernetes 时，我们需要为每一个工作节点上的 Kubelet 分别生成一个证书。由于工作节点可能很多，手动生成 Kubelet 证书的过程会比较繁琐。
为了解决这个问题，Kubernetes 提供了 TLS bootstrapping 的方式来简化 Kubelet 证书的生成过程。其原理是预先提供一个 bootstrapping token，kubelet 通过该 kubelet 调用 kube-apiserver 的证书签发 API 来生成自己需要的证书。
2.3.7.1、 采用TLS bootstrapping 生成证书的流程如下
1、调用 kube-apiserver 生成一个 bootstrap token。
2、将该 bootstrap token 写入到一个 kubeconfig 文件中，作为 kubelet 调用 kube-apiserver 的客户端验证方式。
3、通过 --bootstrap-kubeconfig 启动参数将 bootstrap token 传递给 kubelet 进程。
4、Kubelet 采用bootstrap token 调用 kube-apiserver API，生成自己所需的服务器和客户端证书。
5、证书生成后，Kubelet 采用生成的证书和 kube-apiserver 进行通信，并删除本地的 kubeconfig 文件，以避免 bootstrap token 泄漏风险。
2.3.7.2、 设置集群参数、
kubectl config set-cluster kubernetes \
--certificate-authority=/etc/kubernetes/pki/ca.pem \
--embed-certs=true \
--server=https://20.20.20.88:16443 \
--kubeconfig=/etc/kubernetes/bootstrap-kubelet.kubeconfig2.3.7.3、 设置一个用户
kubectl config set-credentials tls-bootstrap-token-user --token=c8ad9c.2e4d610cf3e7426e --kubeconfig=/etc/kubernetes/bootstrap-kubelet.kubeconfig2.3.7.4、 设置上下文参数
kubectl config set-context tls-bootstrap-token-user@kubernetes --cluster=kubernetes --user=tls-bootstrap-token-user --kubeconfig=/etc/kubernetes/bootstrap-kubelet.kubeconfig2.3.7.5、 设置默认上下文环境
kubectl config use-context tls-bootstrap-token-user@kubernetes --kubeconfig=/etc/kubernetes/bootstrap-kubelet.kubeconfig2.3.7.6、 配置kubectl（管理节点）
[root@master1 ~]# mkdir -p /root/.kube;cp /etc/kubernetes/admin.kubeconfig /root/.kube/config
[root@master2 ~]# mkdir -p /root/.kube;cp /etc/kubernetes/admin.kubeconfig /root/.kube/config
[root@master3 ~]# mkdir -p /root/.kube;cp /etc/kubernetes/admin.kubeconfig /root/.kube/config
[root@master1 ~]# for i in master2 master3;do ssh i:/root/.kube/;doneconfig 100% 6384 1.2MB/s 00:00 config 100% 6384 5.3MB/s 00:00 [root@master1 ~]# kubectl get cs
管理节点配置
[root@master1 ~]# yum install -y bash-completion
[root@master1 ~]# source /usr/share/bash-completion/bash_completion[root@master1 ~]# source <(kubectl completion bash)[root@master1 ~]# kubectl completion bash > ~/.kube/completion.bash.inc[root@master1 ~]# source '/root/.kube/completion.bash.inc' [root@master1 ~]# source $HOME/.bash_profile[root@master1 ~]# vim bootstrap.secret.yaml[root@master1 ~]# kubectl create -f bootstrap.secret.yaml
[root@master1 ~]# kubectl apply -f bootstrap.secret.yaml
2.5 Node节点部署
Master apiserver启用TLS认证后，Node节点kubelet组件想要加入集群，必须使用CA签发的有效证书才能与apiserver通信，当Node节点很多时，签署证书是一件很繁琐的事情，因此有了TLS Bootstrapping机制，kubelet会以一个低权限用户自动向apiserver申请证书，kubelet的证书由apiserver动态签署。
2.5.1 拷贝证书文件
[root@master1 ~]# for i in node1 node2;do ssh $i mkdir -p /etc/etcd/ssl /etc/kubernetes/pki/;scp /etc/etcd/ssl/{etcd-ca.pem,etcd.pem,etcd-key.pem} $i:/etc/etcd/ssl;scp /etc/kubernetes/pki/{ca.pem,ca-key.pem,front-proxy-ca.pem} $i:/etc/kubernetes/pki/;done
[root@master1 ~]# for i in master2 master3 node1 node2;do scp /etc/kubernetes/bootstrap-kubelet.kubeconfig $i:/etc/kubernetes/ ;done2.5.2 部署kubelet（所有节点）
2.5.2.1 所有节点创建目录
[root@master1 ~]# mkdir -p /var/lib/kubelet /var/log/kubernetes /etc/systemd/system/kubelet.service.d /etc/kubernetes/manifests/
2.5.2.2 创建kubelet系统服务
[root@node2 ~]# vim /usr/lib/systemd/system/kubelet.service
[Unit]
Description=Kubernetes Kubelet
After=docker.service
Requires=docker.service
[Service]
ExecStart=/usr/local/bin/kubelet
Restart=on-failure
KillMode=process
[Install]
WantedBy=multi-user.target[root@node2 ~]# vim /etc/systemd/system/kubelet.service.d/10-kubeadm.conf
[Service]
Environment="KUBELET_KUBECONFIG_ARGS=--bootstrap-kubeconfig=/etc/kubernetes/bootstrap-kubelet.kubeconfig --kubeconfig=/etc/kubernetes/kubelet.kubeconfig"
Environment="KUBELET_SYSTEM_ARGS=--network-plugin=cni --cni-conf-dir=/etc/cni/net.d --cni-bin-dir=/opt/cni/bin"
Environment="KUBELET_CONFIG_ARGS=--config=/etc/kubernetes/kubelet-conf.yml --pod-infra-container-image=registry.cn-hangzhou.aliyuncs.com/google_containers/pause:3.4.1"
Environment="KUBELET_EXTRA_ARGS=--node-labels=node.kubernetes.io/node='' "
ExecStart=
ExecStart=/usr/local/bin/kubelet $KUBELET_KUBECONFIG_ARGS $KUBELET_CONFIG_ARGS $KUBELET_SYSTEM_ARGS $KUBELET_EXTRA_ARGS[root@node2 ~]# vim /etc/kubernetes/kubelet-conf.yml
apiVersion: kubelet.config.k8s.io/v1beta1
kind: KubeletConfiguration
address: 0.0.0.0
port: 10250
readOnlyPort: 10255
authentication:
anonymous:
enabled: false
webhook:
cacheTTL: 2m0s
enabled: true
x509:
clientCAFile: /etc/kubernetes/pki/ca.pem
authorization:
mode: Webhook
webhook:
cacheAuthorizedTTL: 5m0s
cacheUnauthorizedTTL: 30s
cgroupDriver: systemd
cgroupsPerQOS: true
clusterDNS:
- 10.96.0.10
clusterDomain: cluster.local
containerLogMaxFiles: 5
containerLogMaxSize: 10Mi
contentType: application/vnd.kubernetes.protobuf
cpuCFSQuota: true
cpuManagerPolicy: none
cpuManagerReconcilePeriod: 10s
enableControllerAttachDetach: true
enableDebuggingHandlers: true
enforceNodeAllocatable:
- pods
eventBurst: 10
eventRecordQPS: 5
evictionHard:
imagefs.available: 15%
memory.available: 100Mi
nodefs.available: 10%
nodefs.inodesFree: 5%
evictionPressureTransitionPeriod: 5m0s
failSwapOn: true
fileCheckFrequency: 20s
hairpinMode: promiscuous-bridge
healthzBindAddress: 127.0.0.1
healthzPort: 10248
httpCheckFrequency: 20s
imageGCHighThresholdPercent: 85
imageGCLowThresholdPercent: 80
imageMinimumGCAge: 2m0s
iptablesDropBit: 15
iptablesMasqueradeBit: 14
kubeAPIBurst: 10
kubeAPIQPS: 5
makeIPTablesUtilChains: true
maxOpenFiles: 1000000
maxPods: 110
nodeStatusUpdateFrequency: 10s
oomScoreAdj: -999
podPidsLimit: -1
registryBurst: 10
registryPullQPS: 5
resolvConf: /etc/resolv.conf
rotateCertificates: true
runtimeRequestTimeout: 2m0s
serializeImagePulls: true
staticPodPath: /etc/kubernetes/manifests
streamingConnectionIdleTimeout: 4h0m0s
syncFrequency: 1m0s
volumeStatsAggPeriod: 1m0s2.5.2.3 启动kubectl
[root@master1 ~]# systemctl daemon-reload[root@master1 ~]# systemctl enable --now kubelet[root@master1 ~]# systemctl status kubelet
[root@master1 ~]# kubectl get node
[root@master1 ~]# kubectl get csr
2.5.2.4 查看证书信息
[root@master1 ~]# openssl x509 -noout -text -in /var/lib/kubelet/pki/kubelet-client-current.pem
Certificate:
Data:
Version: 3 (0x2)
Serial Number:
6f:b4:54:27:54:1a:a5:ed:3c:e7:49:d0:fc:cd:ca:9d
Signature Algorithm: sha256WithRSAEncryption
Issuer: C=CN, ST=Beijing, L=Beijing, O=Kubernetes, OU=Kubernetes-manual, CN=kubernetes
Validity
Not Before: Aug 20 11:11:44 2025 GMT
Not After : Aug 20 11:11:44 2026 GMT
Subject: O=system:nodes, CN=system:node:master1
Subject Public Key Info:
Public Key Algorithm: id-ecPublicKey
Public-Key: (256 bit)
pub:
04:be:66:11:3a:b7:f9:a3:7a:d4:a3:75:30:b7:9d:
47:a9:10:5c:1c:89:6d:f8:3d:d2:42:2c:3c:e3:35:
c1:65:6b:68:75:5c:ab:f3:75:f3:77:ec:33:23:3e:
e5:71:84:3a:d3:86:09:61:63:3d:e4:b7:3b:3f:ef:
57:24:95:09:6b
ASN1 OID: prime256v1
NIST CURVE: P-256
X509v3 extensions:
X509v3 Key Usage: critical
Digital Signature, Key Encipherment
X509v3 Extended Key Usage:
TLS Web Client Authentication
X509v3 Basic Constraints: critical
CA:FALSE
X509v3 Authority Key Identifier:
keyid:3C:83:60:4E:36:FB:2D:FC:46:8B:85:59:99:CE:A2:10:97:60:39:20
Signature Algorithm: sha256WithRSAEncryption
2d:21:30:5b:8a:45:ae:c5:d7:4f:4a:ba:fc:d8:30:8a:bf:0e:
b9:d0:d5:44:c1:77:17:a1:d6:7c:a0:d2:76:ba:fc:ed:43:91:
80:f5:ba:4c:c6:7d:13:cf:bc:13:1a:8f:98:7b:b9:af:fd:f0:
03:99:68:b3:a9:16:bc:04:4e:37:39:86:4e:7d:e0:6b:c0:50:
0f:8d:e1:57:ce:55:09:e1:cf:6c:ab:ec:c5:0f:65:fe:b4:1f:
f5:21:ae:a4:ef:2c:75:e6:8e:e0:84:ae:bb:07:52:e5:54:9a:
ff:7b:6c:94:75:3b:ae:ae:59:c1:84:fe:2d:dc:9f:d7:2a:06:
09:d3:3f:57:e7:68:48:25:cf:e7:15:4c:7c:15:0b:91:2e:e5:
7a:f5:c4:5c:3a:90:3b:de:51:36:cb:8b:3d:1a:47:68:08:43:
d2:84:c0:7f:ce:79:9d:e1:f3:4f:f8:4f:76:e2:db:28:f3:b0:
30:1c:9c:a5:9c:4f:56:a8:1e:15:a1:b2:8b:4b:23:47:bc:e1:
ce:31:b1:17:2f:37:d1:0d:e3:2e:51:c8:81:31:9b:4f:58:31:
e6:0d:d5:2f:df:22:e3:3e:b7:53:d3:3f:d2:6c:aa:7f:f8:43:
f5:53:a0:26:8a:0b:13:28:23:68:c1:f4:a8:5f:b1:6a:f5:eb:
7e:08:fc:422.5.4、 kube-proxy部署
[root@master1 ~]# kubectl -n kube-system create serviceaccount kube-proxyserviceaccount/kube-proxy created[root@master1 ~]# kubectl create clusterrolebinding system:kube-proxy --clusterrole system:node-proxier --serviceaccount kube-system:kube-proxyclusterrolebinding.rbac.authorization.k8s.io/system:kube-proxy created[root@master1 ~]# SECRET=$(kubectl -n kube-system get sa/kube-proxy \
--output=jsonpath='{.secrets[0].name}')[root@master1 ~]# JWT_TOKEN=SECRET > --output=jsonpath='{.data.token}' | base64 -d)
kubectl -n kube-system create serviceaccount kube-proxy
kubectl create clusterrolebinding system:kube-proxy --clusterrole system:node-proxier --serviceaccount kube-system:kube-proxy
SECRET=$(kubectl -n kube-system get sa/kube-proxy --output=jsonpath='{.secrets[0].name}')
JWT_TOKEN=$(kubectl -n kube-system get secret/$SECRET --output=jsonpath='{.data.token}' | base64 -d)2.5.4.2.1、 设置集群参数
kubectl config set-cluster kubernetes \
--certificate-authority=/etc/kubernetes/pki/ca.pem \
--embed-certs=true \
--server=https://20.20.20.88:16443 \
--kubeconfig=/etc/kubernetes/kube-proxy.kubeconfig1.1.1.1、 设置一个用户
[root@master1 ~]# kubectl config use-context kubernetes --kubeconfig=/etc/kubernetes/kube-proxy.kubeconfig1.1.1.1、 设置上下文参数
[root@master1 ~]# kubectl config use-context kubernetes --kubeconfig=/etc/kubernetes/kube-proxy.kubeconfig1.1.1.1、 设置默认上下文环境
[root@master1 ~]# kubectl config use-context kubernetes --kubeconfig=/etc/kubernetes/kube-proxy.kubeconfig1.1.1.1、 创建kube-proxy kubeconfig文件
[root@master1 ~]# vim /etc/kubernetes/kube-proxy.conf
apiVersion: kubeproxy.config.k8s.io/v1alpha1
bindAddress: 0.0.0.0
clientConnection:
acceptContentTypes: ""
burst: 10
contentType: application/vnd.kubernetes.protobuf
kubeconfig: /etc/kubernetes/kube-proxy.kubeconfig
qps: 5
clusterCIDR: 172.168.0.0/16
configSyncPeriod: 15m0s
conntrack:
max: null
maxPerCore: 32768
min: 131072
tcpCloseWaitTimeout: 1h0m0s
tcpEstablishedTimeout: 24h0m0s
enableProfiling: false
healthzBindAddress: 0.0.0.0:10256
hostnameOverride: ""
iptables:
masqueradeAll: false
masqueradeBit: 14
minSyncPeriod: 0s
syncPeriod: 30s
ipvs:
masqueradeAll: true
minSyncPeriod: 5s
scheduler: "rr"
syncPeriod: 30s
kind: KubeProxyConfiguration
metricsBindAddress: 127.0.0.1:10249
mode: "ipvs"
nodePortAddresses: null
oomScoreAdj: -999
portRange: ""
udpIdleTimeout: 250ms[root@master1 ~]# vim /usr/lib/systemd/system/kube-proxy.service
[Unit]
Description=Kubernetes Kube Proxy
Documentation=https://github.com/kubernetes/kubernetes
After=network.target
[Service]
ExecStart=/usr/local/bin/kube-proxy \
--config=/etc/kubernetes/kube-proxy.conf \
--v=2
Restart=always
RestartSec=10s
[Install]
WantedBy=multi-user.target1.1.1.1、 分发kubeconfig配置文件
for i in master1 master2 master3 node1 node2 ;do scp /etc/kubernetes/kube-proxy.kubeconfig $i:/etc/kubernetes/;scp /etc/kubernetes/kube-proxy.conf $i:/etc/kubernetes/kube-proxy.conf;scp /usr/lib/systemd/system/kube-proxy.service $i:/usr/lib/systemd/system/kube-proxy.service;done
1.1.1.1、 启动kube-proxy**（所有节点）**
[root@master1 ~]# systemctl daemon-reload[root@master1 ~]# systemctl enable --now kube-proxy[root@master1 ~]# systemctl status kube-proxy
2.6 使用calico安装k8s网络
2.6.1 官方yaml文件下载地址：
[root@master1 ~]# wget https://docs.projectcalico.org/manifests/calico-etcd.yaml
2.6.2 修改calico-etcd.yaml的命令：
sed -i 's#etcd_endpoints: "http://<ETCD_IP>:<ETCD_PORT>"#etcd_endpoints: "https://20.20.20.56:2379,https://20.20.20.57:2379,https://20.20.20.13:2379"#g' calico-etcd.yaml
sed -i \
-e 's|docker.io/calico|registry.aliyuncs.com/google_containers/calico|g' \
-e 's|imagePullPolicy: Always|imagePullPolicy: IfNotPresent|g' \
calico-etcd.yaml
sed -ri 's|/calico-secrets/etcd-ca|/etc/etcd/ssl/etcd-ca.pem|' calico-etcd.yaml
sed -ri 's|/calico-secrets/etcd-cert|/etc/etcd/ssl/etcd.pem|' calico-etcd.yaml
sed -ri 's|/calico-secrets/etcd-key|/etc/etcd/ssl/etcd-key.pem|' calico-etcd.yaml
ETCD_CA=`cat /etc/kubernetes/pki/etcd/etcd-ca.pem | base64 | tr -d '\n'`
ETCD_CERT=`cat /etc/kubernetes/pki/etcd/etcd.pem | base64 | tr -d '\n'`
ETCD_KEY=`cat /etc/kubernetes/pki/etcd/etcd-key.pem | base64 | tr -d '\n'`
sed -i "s@# etcd-key: null@etcd-key: ${ETCD_KEY}@g; s@# etcd-cert: null@etcd-cert: ${ETCD_CERT}@g; s@# etcd-ca: null@etcd-ca: ${ETCD_CA}@g" calico-etcd.yaml
sed -i 's#etcd_ca: ""#etcd_ca: "/calico-secrets/etcd-ca"#g; s#etcd_cert: ""#etcd_cert: "/calico-secrets/etcd-cert"#g; s#etcd_key: "" #etcd_key: "/calico-secrets/etcd-key" #g' calico-etcd.yaml #添加etcd证书地址
POD_SUBNET="172.168.0.0/16"
sed -i 's@# - name: CALICO_IPV4POOL_CIDR@- name: CALICO_IPV4POOL_CIDR@g; s@# value: "192.168.0.0/16"@ value: '"${POD_SUBNET}"'@g' calico-etcd.yaml
#修改我们pod地址段，需要和上面配置一样
sed -i 's/command: \["calico-node", "-init", "-best-effort"\]/command: \["calico-node", "-init"\]/' calico-etcd.yaml
cfssl gencert -ca=/etc/kubernetes/pki/ca.pem -ca-key=/etc/kubernetes/pki/ca-key.pem -config=ca-config.json -hostname=127.0.0.1,20.20.20.88,172.17.0.1,kubernetes,kubernetes.default,kubernetes.default.svc,kubernetes.default.svc.cluster,kubernetes.default.svc.cluster.local,20.20.20.56,20.20.20.57,20.20.20.13 -profile=kubernetes apiserver-csr.json | cfssljson -bare /etc/kubernetes/pki/apiserver
#实际操作
[root@master1 ~]# sed -i 's#etcd_endpoints: "http://<ETCD_IP>:<ETCD_PORT>"#etcd_endpoints: "https://20.20.20.56:2379,https://20.20.20.57:2379,https://20.20.20.13:2379"#g' calico-etcd.yaml
[root@master1 ~]# ETCD_CA=`cat /etc/kubernetes/pki/etcd/etcd-ca.pem | base64 | tr -d '\n'`
[root@master1 ~]# ETCD_CERT=`cat /etc/kubernetes/pki/etcd/etcd.pem | base64 | tr -d '\n'`
[root@master1 ~]# ETCD_KEY=`cat /etc/kubernetes/pki/etcd/etcd-key.pem | base64 | tr -d '\n'`
[root@master1 ~]# sed -i "s@# etcd-key: null@etcd-key: ${ETCD_KEY}@g; s@# etcd-cert: null@etcd-cert: ${ETCD_CERT}@g; s@# etcd-ca: null@etcd-ca: ${ETCD_CA}@g" calico-etcd.yaml
[root@master1 ~]# sed -i 's#etcd_ca: ""#etcd_ca: "/calico-secrets/etcd-ca"#g; s#etcd_cert: ""#etcd_cert: "/calico-secrets/etcd-cert"#g; s#etcd_key: "" #etcd_key: "/calico-secrets/etcd-key" #g' calico-etcd.yaml
[root@master1 ~]# POD_SUBNET="172.168.0.0/16"
[root@master1 ~]# sed -i 's@# - name: CALICO_IPV4POOL_CIDR@- name: CALICO_IPV4POOL_CIDR@g; s@# value: "192.168.0.0/16"@ value: '"${POD_SUBNET}"'@g' calico-etcd.yaml
[root@master1 ~]# sed -i 's/command: \["calico-node", "-init", "-best-effort"\]/command: \["calico-node", "-init"\]/' calico-etcd.yaml
[root@master1 ~]# sed -i \
> -e 's|docker.io/calico|registry.aliyuncs.com/google_containers/calico|g' \
> -e 's|imagePullPolicy: Always|imagePullPolicy: IfNotPresent|g' \
> calico-etcd.yaml手动拉取镜像
#临时去除node节点污点
[root@master1 calico]# for node in $(kubectl get nodes -o name); do
> kubectl taint node $node node.kubernetes.io/not-ready:NoSchedule-
> done
node/master1 untainted
node/master2 untainted
node/master3 untainted
node/node1 untainted
node/node2 untainted
docker pull docker.m.daocloud.io/calico/cni:v3.25.0
docker pull docker.m.daocloud.io/calico/node:v3.25.0
